    PLANAR MAGNETICS GUIDELINE

    PL14 & PL18 SERIES....... Optimum 10W-100W forward converter application, wide spread use in 1/8, 1/16 brick footprint
    PL40, PP40, PI40 Inductor SERIES...... Ideal for Telecom Application for power 30-200W
    PL58, PP58 SERIES....... Rated to 300W Active Clamp Forward at 250 KHz & 600W 250KHz ZVT Bridge
    PL58 AC SERIES.....Designed 8mm Creepage over 3750VAC Dielectric Isolation. Rated 100W-1KW
    "PEACOCK" SERIES........ Rated to 800W & Unique Thermal Spread Solution
    PL80 SERIES........Rated to 1KW + Worldwide use in AC Adaptor to 300W
    PLEE125 & PLEE200 SERIES......Rated 50W-1KW. “Legacy Planar Product” – that is – De Facto Standard sizes originating from 1980s – Still Supported
    PLEE500 & PLEE1000 SERIES.... Rated 500W-10KW | Worldwide use PFC& UPS. Excellent High Current Capability in Volumetrically Efficient Package

    Planar Magnetics Categories
    • "New" ER Type Ferrite Cores
    • Size 14, 35, 40, 55, 58, 80, 135, 250, 500, 1000-
    • Conventional EE Type Ferrite Cores
    • Size 18, 50, 125, 200, 250, 500, 1000
    • Custom OEM Ferrite Cores - Size PQ 20, 26 | RM 6, 8, 10, 12 | EER 25, 28, 32
    • PCB Manufacturing & Component Assembly -- Planar Magnetics Ferrite
    • Planar Ferrite Magnetic Components Embedded Directly into PCB
    • Planar Magnetics Ferrite Integrated into 1/4 1/8 & 1/16 Size DC-DC "Bricks"
