Mission Statement
To be the leading planar magnetic design & manufacture company in the world, renowned for its technological expertise and well recognized as a front-runner in planar design and manufacture.
To maintain close relations with our customers and provide them with products that will suit best their total power solutions
To capitalize on the links with leading academic institutes for rapid access to the latest developments in power IC circuit design as well as to provide continuing training and development on the latest technologies and design methodologies to our engineers.
To capitalize on our management expertise in the transformer industry and power supply industry in order to timely develop next generation products.
PLANAR MAGNETICS GUIDELINE
PL14 & PL18 SERIES.......Optimum 10W-100W forward converter application, wide spread use in 1/8, 1/16 brick footprint
PL40, PP40, PI40 Inductor SERIES...... Ideal for Telecom Application for power 30-200W
PL58, PP58 SERIES....... Rated to 300W Active Clamp Forward at 250 KHz & 600W 250KHz ZVT Bridge
PL58 AC SERIES.....Designed 8mm Creepage over 3750VAC Dielectric Isolation. Rated 100W-1KW
"PEACOCK" SERIES........ Rated to 800W & Unique Thermal Spread Solution
PL80 SERIES........Rated to 1KW + Worldwide use in AC Adaptor to 300W
PLEE125 & PLEE200 SERIES......Rated 50W-1KW. “Legacy Planar Product” – that is – De Facto Standard sizes originating from 1980s – Still Supported
PLEE500 & PLEE1000 SERIES.... Rated 500W-10KW | Worldwide use PFC& UPS. Excellent High Current Capability in Volumetrically Efficient Package
Planar Magnetics Categories
Quality Standards
