PL14
& PL18 SERIES.......
Optimum 10W-100W forward converter application,
wide spread use in 1/8, 1/16 brick footprint
PL40,
PP40, PI40
Inductor SERIES...... Ideal for Telecom
Application for power 30-200W
PL58,
PP58 SERIES.......
Rated to 300W Active Clamp Forward at 250 KHz & 600W 250KHz ZVT Bridge
PL58
AC SERIES.....Designed 8mm Creepage over
3750VAC Dielectric Isolation. Rated 100W-1KW
"PEACOCK"
SERIES........ Rated to 800W & Unique
Thermal Spread Solution
PL80 SERIES........Rated
to 1KW + Worldwide use in AC Adaptor to 300W
PLEE125
& PLEE200 SERIES......Rated
50W-1KW. “Legacy Planar Product”
– that is – De Facto Standard sizes originating from 1980s
– Still Supported
PLEE500
& PLEE1000 SERIES.... Rated
500W-10KW | Worldwide use PFC& UPS. Excellent High Current Capability
in Volumetrically Efficient Package
|
|
Planar Magnetics Categories
|
|
|
|
|
|
|
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
- Champs Technologies offers a Std Design Series of Planar Magnetics.
A Broad Power Conversion Range.
- Champs Original Designs offer performance advantages
- Champs will Integrate Planar into DC-DC Converters
- Competitive Cross Reference to Pulse Engineering, Payton, Planar Quality,
Planar Magnetics. Champs can build any planar device.
- Experience. We have been building planar since 1992.
- OEM Planar: Supplier to Major Asian OEM manufacturers.
- Flexibility. You will find that Champs will build your Planar Design
whether it is 1pc, 10pcs, or 10K or 100K
- Conventional Magnetics: We are not exclusively planar. We offer the
entire universe of conventional magnetics
- Competitive Advantage. Champs can improve your approach to power conversion.
Consult with Us.
|
|
|
